Specs
| Motor: |
Permanent Split Capacitor |
|---|---|
| Horse Power: |
1/4 |
| Voltage: |
208/230v |
| Amperage: |
2.2 |
| RPM: |
1075 |
| Speeds: |
1 |
| Capacitor: |
370 VAC |
| Hertz: |
60 |
| Mount: |
Shaft up, shaft down, or belly band |
| Insulation Class: |
B |
| Bearings: |
Sleeve |
| Finish: |
Grey-green powdercoat |
| Frame Size: |
48 |
| Rotation: |
CW/CCW |
| Temperature Rating: |
60 deg C / 140 deg F |
| Lead Wire Length: |
30 inches |
| Lead Wire Gauge: |
#18 AWG |
| Motor Diameter: |
5.59″ |
| Motor Length: |
10.584″ |
| Shaft Diameter: |
1/2″ |
| Shaft Flats: |
One flat |
| Weight (lbs): |
12.1 lbs |
